ADDERLink INFINITY 2122
Manufacturer
Produced In
United Kingdom
Product Description
The ADDERLink INFINITY 2122 is a high performance IP KVM extender that forms part of the ALIF matrix solution.
This enables the relocation of critical computing hardware into a secure and temperature controlled environment away from the user work station; while maintaining a pixel-perfect desktop experience.
Key Features
- Perfect Digital Video, Real-Time Control - Using a spatially-lossless encoding system, with 1:1 pixel mapping, the ALIF2122 provides pixel-perfect and color accurate video with no artifacts. The digital video received is the same as the digital video leaving the remote computer.
- Standard IP Technology - Using standard IP technology allows a choice of CATx or fiber connections (1x RJ45 1GbE SFP module included). Resilience is offered by the optional 2nd network port which provides teaming facility for load balanced and critical systems.
- Unlimited Extension Distances - Extension distance is not limited to a single 100 meter cable length. If you need to extend further, simply add a 1GbE network device to achieve an additional 100 meters, which can be repeated many times. Also fitted with SFP cages to accept fiber optic transceivers for much greater distances.
- USB 2.0 with Class Control - Supports USB devices including graphics tablets, jog shuttles, joysticks and 3D explorers, alongside mass storage devices. For secure applications, the system can disable the use of non-HID devices, meaning there is no need to physically block USB ports to prevent the use of mass storage devices.
- Flexible and Scalable Extender or Switch - Each ALIF2100 series unit can be configured as a simple extender or self-managed distributed KVM switch. Each receiver can see up to 16 sources and rapidly switch between them.
- ADDERLink® INFINITY Matrix - With the addition of the ADDERLink INFINITY management system (AIM), you can turn multiple point-to-point extenders into a truly scalable digital KVM matrix system that allows any workstation to link with any computer connected to the network. See the AIM datasheet for details.
- EDID Management - Intelligent EDID management allows the true characteristics of the monitor to be passed back to the computer. This ensures perfect video display without additional configuration.
- Plug and Play - ADDERLink INFINITY devices are delivered in a zero config state so you can plug them in and start working on them straight away. There is no need for drivers or software to be installed.
- Redundant Network Operation - The units support network teaming allowing for full network redundancy and increased resilience for mission-critical applications.
- Digital Audio - The ALIF2100 series supports two-channel digital audio input via USB and the digital video connector.
- Dual-Touch Screen Support - Dual-touch screen support including on-screen keyboard and floating launch button with configurable size which can be positioned anywhere on the screen.
- Support for Dithered Video - Allows analog or noisy video to pass through the system along with computer that dither the video to enhance the perceptive image quality. Some Mac® computers use this technique.
- Receiver connectivity options - The ADDERLink INFINITY 2000 series receiver supports native DisplayPort connectivity and HDMI connectivity via VSCD19 or VSCD20 DisplayPort to HDMI adaptor cables.
- Transmitter connectivity options - Support for both DisplayPort (2122) and HDMI (2124) transmitter connectivity options ensure ultimate flexibility and ease of deployment.
Product Code
Product Name
Add to Basket
ADDERLink INFINITY 2122
ALIF2122T
ADDERLink INFINITY 2122 Transmitter
ALIF2122R
ADDERLink INFINITY 2122 Receiver
