Aten KL1508A

Get a Quote
Manufacturer
Produced In
Taiwan
Download Aten KL1508A Data Sheet

Product Description

The Aten KL1508A Dual Rail LCD KVM Switch is a control unit that allows secure access to 8 computers from a single KVM (keyboard, video, and mouse) console. It consists of an integrated 17" or 19" LCD monitor, keyboard, and touchpad mouse in a 1U rack-mountable retractable sliding housing.

VGA, DVI, HDMI and DisplayPort video; PS/2 or USB control

The LCD and keyboard/touchpad modules slide independently of each other. To maximize space in your data center, the keyboard/touchpad module slides back to “ hide away ” when not in use, while the thin profile LCD monitor rotates back – flush against the rack – allowing convenient monitoring of computer activity.

Key Features

  • Integrated KVM console with 17 or 19 inch screen keyboard & mouse
  • A single console controls up to 8 computers
  • Daisy chain up to 15 additional KVM switches to control up to 128 computers*
  • Space-saving RJ-45 connectors and Cat 5e/6 cabling
  • Extra console port manage computers in the LCD KVM switch from an external console (monitor, USB or PS/2 keyboard, and USB or PS/2 mouse)
  • Multiplatform support: PC, Mac, Sun and Serial
  • Supports external USB mouse
  • Dual Rail housing is slightly less than 1U with top and bottom clearance for smooth operation in 1U of rack space
  • Dual Rail 17“ LCD monitor slides independently of the keyboard/touchpad
  • LCD module rotates up to 120 degrees for a more comfortable viewing angle
  • End session feature administrators can terminate any running session
  • Port Share Mode allows multiple users to gain access to a server simultaneously
  • Event logging and Windows-based Log Server support
  • Firmware upgradeable
  • Easy computer selection via pushbuttons, Hotkey Mode, OSD (OnScreen Display), and Browser-based GUI
  • Multiplatform client support (Windows, Mac OS X, Linux, Sun)
  • Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory
  • Configurable user and group permissions for server access and control
  • Message board feature allows logged in users to communicate with each other
  • BIOS-level access

Product Code

Product Name

Add to Basket

Aten KL1508A 17" or 19" Dual Rail Rack mount console with keyboard and mouse & integrated 8 port KVM switch
KL1508AM
17" Dual Rail Rack mount console with keyboard and mouse & integrated 8 port KVM switch

KL1508AN
19" Dual Rail Rack mount console with keyboard and mouse & integrated 8 port KVM switch
