XCALIBUR 11 -HDMI 2.0 Extender supports 4K @60hz 4:4:4 to 120m & 1080p to 150m

Produced In

Product Description

Xcalibur-11 - HDMI Extender using HX Technology -  This amazing Extender can extend HDMI 2.0 (4K60 4:4:4) signals to 120m and 1080p signals to 150m. Furthermore, it supports HDR, HDR10, HDR10+, HLG and Dolby vision, as well as HBR, and all sound formats to 7.1 channels.  Perfect for most professional installations.

The Xcalibur-11 Transmitter unit also facilitates an HDMI Loop-out, whilst the Receiver unit provides De-embedded Audio output. The system rather features rich, with some diagnostic tools as well as very useful features.

Xcalibur-11 has many features such as Bi-directional IR, RS232 Pass-Through, RS232 Control, Down Scaling, Test Pattern Generator, VKA, PoC, HDCP and EDID management. In addition, the Receiver unit has an analogue Audio De-embed Output.

Long Range transmission - It will transmit HDMI 2.0 video signals to 150m @1080p or 120m @4K60 4:4:4 over a Cat6 cable, utilising T568B wiring standard.

HDR - The Xcalibur product range supports HDR, HDR10, HDR10+, HLG and Dolby vision.

Down Scaling - The Transmitter unit has a built-in Down-Scaler that may be used in either Auto Mode (default) or selected manually.  4K signals can be scaled down to 1080p while retaining the Refresh Rate, (frame rates are always preserved). As an example, a 4K source can be displayed on a 1080p display automatically while in Auto mode.
The HDMI loop-out is a Pass-Through port, and as such is not affected by the Scaler.

HDCP Control - Support and ‘Management of HDCP’ ensures compatibility. The HDCP can be set independently for the HDMI Input, HDMI Loop Out and HX outputs. You can convert from HDCP 2.2 down to HDCP 1.4, or simply put the unit into Cascade Mode - No more HDCP issues.

EDID Management - As well as pass-through, there is a user-programmable EDID memory option. The choices include ‘Use EDID from User memory’, ‘Use EDID from HDMI output’ or ‘Use EDID from HX output’.  This facility can ensure the video source is optimised to suit the installation.

Test Pattern Generator - We have equipped this Professional device with an on-board ‘Test Pattern Generator’ complete with a choice of 6 Test Patterns including Checkerboard or Solid Colour Patterns, at 4K@60, 4K@30, 1080p@60. Perfect for commissioning or checking all the component parts from the transmitter to the display.

VKA - The ‘Video Keep Alive’ option, maintains video output whenever the input video is lost. This function can be very useful, particularly when used with projectors, which may otherwise shut down and then run a long cool down sequence. The unit can output a currently selected Test Pattern to prevent the display device from powering down. By default, it is in 'VKA OFF mode'.  Other options include ‘VKA Timed mode’ with a user-programmable time-out interval of up to 4 hours long or maintained indefinitely until the input signal is resumed.

Audio Support – Pass-through of audio signals up to 7.1 channels for connection to a surround sound system with an HDMI input.

Audio De-embedder - The Receiver unit has Audio De-embedding available via a 3.5mm jack as stereo analogue audio.

Control - The Xcalibur-11 is equipped with pass-through bi-directional IR ports and an RS232 pass through the port. The Transmitter/Receiver units can also be controlled through the USB interface, to adjust the various parameters.

CEC - The device will pass through all CEC commands from input to output.

PoC - (Power over Cable) Only one 24V PSU is required to power both Transmitter and Receiver units, from either end.

Xcalibur is an innovative product range, comprising of multiple features that complement the HX technology perfectly. This cost-effective system is ideal for use in all applications including Digital Signage, Education, Office Displays, Meeting Rooms, Residential including Hi-Spec Home Cinema.


Key Features

  • HDMI 2.0 (18Gbps) 4K60 4:4:4 in and out
  • HDMI Loop-out + HX outputs
  • 1080p to 150m, 4K60 to 120m over cat6 cable
  • HDR, HDR10, HDR10+, HLG and Dolby vision
  • Down Scaler – 4K to 1080p
  • Bi-directional IR
  • RS232 pass-through and control
  • CEC pass-through
  • Audio Analogue De-embedder
  • EDID and HDCP Control/management
  • Test Pattern Generator – Various patterns
  • VKA (Video Keep Alive)
  • PoC – Power from either end

Product Code

Product Name

Add to Basket

Extender Model
Xcalibur 11 4K 18G Extender. 150m @1080p or 120m @ 4K 60HZ 4:4:4, HDMI local loop out, 4K60-1080p Scaler, Supports POC
