Aten RCM416VA / RCM432VA / RCM464VA / RCM416A / RCM816A The Remote Control & Monitoring (RCM) Series of KVM over IP Switches
Product Description
The RCM Series of KVM over IP switches (RCM416VA / RCM432VA / RCM464VA / RCM416A / RCM816A) provides local console and remote over IP access for users to monitor and access their entire data center over a network. The RCM series offers superior FHD video resolution up to 1920 x 1200, virtual media transmissions at double speed, FIPS 140-2 with level 1 security standards by using an embedded FIPS 140-2 certified OpenSSL cryptographic module. Equipped with dual on-board NICs, the RCM series is built to ensure reliability and availability of remote access to all servers.
The RCM series is compatible with ATEN’s KVM over IP Console Station – the KA82 series. The KA82 series is a standalone console that replaces PC or NB, enabling users to remotely access, monitor and control all servers connected to multiple ATEN’s RCM series with impenetrable security against virus threats. It is especially suitable for environments where a PC is not allowed.
In addition, the RCM series works with ATEN’s PDU remote power management systems from the KVM over IP switches’ user interface.
Key Features
- Laptop USB Console (LUC) – a dedicated USB port directly connects to a laptop for easy console operation
- 4/8 separate buses for remote KVM over IP access
- Two 10 / 100 / 1000 Mbps NICs for redundant LAN or two IP operation
- Blade server support
- Supports PS/2, USB, Sun Legacy and serial (RS-232) connectivity
- Multiplatform server environments: Windows, Mac, Sun, Linux and VT100 based serial devices
- Dual power supply (RCM416VA, RCM432VA, RCM464VA)
- Video resolution up to 1920 x 1200 @ 60 Hz; 24-bit color depth
