Rose UltraVista Plus
Product Description
The Rose Electronics VWL-D122DDL UltraVista Plus is the perfect addition to an existing video wall system or a new one.The UltraVista Plus accepts a standard single or dual-link DVI input signal and displays ¼ of it across four output monitors.
The system is easy to install and UltraVista Plus’s versatility allows for very creative and unique video wall arrangements.
A video wall can consist of a mix of portrait and landscape displays. To support portrait oriented monitors, the selected region of the input image can be rotated by 90º, 180º or 270º to fit and align with the output monitor.Each output can be driven as DVI or analog RGB and can be any selected area of the input image.
The UltraVista Plus can display the input signal in full on each output display, divide the input signal into quadrants and display each quadrant in a 2x2 display array, optionally convert the frame rates, crop the input signal, upscale specific areas, and much more. With the UltraVista Plus you can design your video wall in different variations and layouts that are sure to attract an audience.
Key Features
- Single or dual link DVI input support
- Max output resolution 2048 x 2048
- Full bezel width and height correction
- Splits a single DVI input into four independent outputs
- Output monitors can be DVI or Analog RGB
- Each output monitor can display any selected area of the input image
- Auto-detection of input resolution and output monitor resolution
- Default setting displays ¼ of the input signal on each output monitor in a 2x2 array.
- Each output monitor can display any rectangular section of the input video signal
- The graphical utility provides easy configuration for cropping, scaling, rotating, and gap compensation.
- Power, status, and input indicators
- The firmware detects when the input and output timings are set to identical frame rates and will automatically genlock the syncs.
